Trusted Platform Module 2.0 (TPM 2.0)
NS350

Key Features
 Compliant to TCG TPM Main Specification, Family "2.0", Level 00, Revision 01.59 - errata 1.4 and PC Client Specific TPM Platform Specification 1.05 revision 14
 Targeted certifications:
o Common Criteria (CC), Version 3.1 Revision 5, Level EAL4+, AVA_VAN.4, ALC_FLR.1, according to TCG PC Client TPM 2.0 Protection Profile Version 1.3
o FIPS 140-2 level 2 (physical security level 3)
o TCG certification
 SPI Interface support at up to 50 MHz
 Standard (-20~+85°C) and Enhanced (-40~+85°C) temperature range
 QFN32 package
 1.8v or 3.3v supply voltage range
 Optimized for battery operated devices: low standby low power consumption (typical 70uA)
 Active shield and environmental sensors
 Monitoring of environmental parameters (power, temperature)
 Hardware and software protection against fault injection
 Random Number Generator (RNG) implemented according to NIST SP800-90A using entropy source according to NIST SP800-90B
 24 PCRs (SHA1, SHA-256 or SHA384)
 RSA key generation (2048, 3072 and 4096 bit)
 ECC (NIST P_256, NIST P_384)
 SHA1, SHA256, SHA384
 Full personalization with 3 EK certificates (RSA 2048, RSA 3072, ECC NIST P384)
 Compliant with the TCG test suite for TPM 2.0
 Field Upgrade - allows secure firmware updates
Note : 11 : Only Single Wire    Y : Only LCD Mode   “-” : Not Supported
Note : 11 : Only Single Wire    Y : Only LCD Mode   “-” : Not Supported
Note : 11 : Only Single Wire    Y : Only LCD Mode   “-” : Not Supported
